Model

NE1300G M ATX3.1

Type

ATX 12V 3.1

Dimension

140(L) × 150(W) × 86(H) mm

Modular

Full-Modular

Input Voltage

100V–240V

Input Current

15A–7.5A

Input Frequency Range

50Hz–60Hz

PFC

Active PFC

Power Good Signal

100–150 ms

Protection

OCP, OVP, UVP, SCP, OPP, OTP, SIP, NLO

Output Capacity

1300W

Operation Temperature

0 ~ 40°C

Regulatory

cTUVus, TUV, CB, RCM, CE, FCC, BIS, BSMI, KC, UKCA, ICES

Fan

120mm FDB Silent Fan

Certifications

80 Plus Gold

Connector

1 × 24(20+4) pin MB
1 × 16(12+4) pin PCIe 5.1 12V-2x6
2 × 8(4+4) pin CPU
4 × 8(6+2) pin PCI-E
12 × SATA
4 × Molex

Net Weight

1.66 kg

Gross Weight

4.68 kg

UPC

0-761345-11396-0 (NE1300G M ATX3.1)
0-761345-11397-7 (NE1300G M ATX3.1 AU)
0-761345-11398-4 (NE1300G M ATX3.1 EC)
0-761345-11399-1 (NE1300G M ATX3.1 GB)
0-761345-11430-1 (NE1300G M ATX3.1 JP)
