Model

PRIME-650B-BLACK

Intel Form Factor

ATX12V

PFC Type

Active PFC

Dimensions

150 x 150 x 86 mm

Efficiency

80Plus Bronze

MTBF

>120,000 hrs @ 25°C

Protection Features

OPP / OVP / UVP / SCP / OCP / OTP

Hazardous Materials

ROHS

AC Input Range

100–240Vac

DC Output Voltage

+3.3V, +5V, +12V, -12V, +5Vsb

Maximum Load

20A, 20A, 54A, 0.3A, 2.5A

Combined Load

110W, 110W, 648W, 3.6W, 12.5W

Total Output

650W

Cable Connectors

MB 24/20-pin x 1
CPU 4+4-pin x 1
PCI-E 8-pin x 2
SATA x 5
PERIPHERAL x 3

Package Contents

Power Cord x 1
CPU cable x 1 (800mm)
PCI-E 1-to-2 x 1 (600mm)
SATA 1-to-2 cable x 1 (400+120mm)
SATA 1-to-3 cable x 1 (400+120+120mm)
Peripheral 1-to-3 cable x 1 (400+120+120mm)
User Manual x 1

Weight

Single PSU: 2.2KG
With packing: 3.067KG

0dB Technology

No

0dB Fan Button

No, this product is without 0dB technology
